وصف
|
01 |
02 |
|
Alloy aluminum material Light weight and high strength Good sealing performance |
Precision thread Thread gauge teeth are uniform and fine Exquisite appearance and good tightness The connection shall be firm without stripping off |
|
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
|
Place empty box barometer |
Electrical interface |
Viewing window |
Top cover |
Sealing buckle |
Pressure transmission hose |
Material: alloy aluminum |
Connection joint |
|
Product name |
Empty box air pressure device |
|
Model |
ALKA18H |
|
Absolute pressure range |
50~1300hPa.abs |
|
Measuring range |
-0.95~0.25bar |
|
Material |
Alloy aluminum |
|
Pressure transmission hose |
1000mm |
|
Electrical interface |
Four-core, can provide power connection for charged products without voltage leakage |
|
Net Weight |
Approximately 22.7kg |
|
Product size |
φ350×250mm |
|
inside diameter |
φ300×200mm |
|
Packaged weight |
Approximately 28kg |
|
Product packaging size |
450×450×350mm |
