The input liquid level transmitter alktrspt503 has the advantages of simple installation, convenient use, strong interchangeability, high sensitivity, fast response, accurate reflection of the subtle changes of flowing or static liquid level, and high measurement accuracy. It can be directly installed on the process pipeline. 4-20madc two-wire signal transmission, strong anti-interference ability, long transmission distance. In the range of using conditions, the precision is stable for a long time.
Main technical parameters
Measurement range: 0 ~ 100m (default 5m)
Accuracy: grade 0.5
Output: 4 ~ 20 mA.DC Two line system
Electrical connection: M20 × 1.5 internal thread
Temperature range: - 20 ~ 70 ℃
Temperature effect: zero point error will be ± 1% FS / 50 ℃
Waterproof and dustproof: IP65
Probe protection grade: IP68
Anti vibration: frequency ≤ 150Hz, acceleration ≤ 2G
