The working principle and advantages of magnetic flapper level gauge

The magnetic flap level gauge uses the principle of connecting pipe, and a bypass pipe is installed outside the tank. A liquid level indicator is installed outside the bypass pipe to put the floating ball with magnet into the bypass pipe. Because a magnet opposite to the floating ball is installed in the magnetic color chip, when the floating ball rises, it will attract the magnetic color chip to flip, and the color of the magnetic color chip will turn from white to red to indicate the actual liquid level Height. Magnetic switch can also be installed outside the bypass pipe as electrical contact signal output, or liquid level transmitter can be installed for remote liquid level signal transmission and liquid level control.

Product advantages:

1. Simple structure, reliable and durable, can be equipped with a variety of options to make control easier;
2. The liquid level transmitter and magnetic switch can be installed or adjusted at any time without shutdown;
3. There is no dead angle of the magnetic line of force of the floating ball, which can be induced at 360 degrees;
4. The flap indicator is modular, with red, green and white colors, which can be used to confirm the liquid level on site; it is also made of porcelain, which is resistant to high temperature and will not fade, and each 10cm is a color chip of different colors, which makes the liquid level easy to identify.
5. The magnetic spring module of remote liquid level transmitter is designed with stable and reliable signal output.
It is widely used in industrial waste water treatment equipment, such as kerosene finishing and heat treatment equipment, dyeing equipment, etc
