Description
Overviews
Armored thermal resistance wzpk-173s is a kind of temperature sensor, which is smaller than the fabricated resistance in diameter, easy to bend and good in anti-seismic performance. It is suitable for installation where the fabricated platinum resistance cannot be installed. It has the advantages of accuracy, sensitivity, fast thermal response time, stable quality and long service lif
Specification
|
Warranty |
1years |
|
Place of Origin |
China |
|
|
Jiangsu |
|
Brand Name |
AILEIKE |
|
Model Number |
WZPK-173S |
|
Size: |
custom |
Product application
Type selection
Technical index
Dividing numberPt100:A Ro=100 ±0.06Ω
Class B Ro=100 ±0.12Ω
Range specification
|
Type number |
Dividing number |
Temperature range ℃ |
Precision grade |
Allowable deviation t ℃ |
|
WZPK |
Pt100 |
-200 / 500 |
Class A |
±(0.002 or + 0.002 / t /) |
|
Class B |
±(0.3 or + 0.005 / t /) |
Note: In the formula, "t" is the absolute value of measured temperature of temperature sensing element
