Description
|
01 |
02 |
03 |
|
Reasonable structure be easy to carry about Can be used for on-site measurement Use of pressure generating device |
Pre press button Boost button Pressure reducing button Dynamic response stability Good sealing performance |
The operation panel is clear and intuitive Can enable operators to learn without a teacher Wide range of measurement |
|
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
12 |
|
Pressure relief valve |
Oil cup |
Pressure Output Port 1 Connecting threads： M20X1.5 |
Pressure Output Port 2 Connecting threads： M20X1.5 |
Pre press button |
Fine tuning pump |
Stop valve |
Pressure relief button |
Boost button |
Carrying handle |
Power Socket |
Power switch |
|
Product name |
Electrodynamic calibration table |
|
Model |
ALKD91B |
|
Measuring range |
0~600bar /0~8700psi/0~60MPa(Optional within the range) |
|
Accuracy |
Pressure:0.05%F.S Pressure:0.02%F.S |
|
Output port |
Two |
|
Drift |
<0.01%F.S/year |
|
Power Consumption |
<500VA |
|
Pressure fluctuation range |
0.05%F.S/5S |
|
Temperature |
15~35℃ |
|
Measurement Medium |
Transformer oil 25# |
|
Measurement medium |
0~80%RH |
|
Pressurization method |
AC220±10% 50Hz |
|
Measurement medium |
Non-Corrosive gas |
|
Net Weight |
Approximately 21.2kg |
|
Product size |
450×440×415mm |
|
Packaged weight |
Approximately 31kg (packaging material is Wooden box) |
|
Product packaging size |
550×540×515mm |
