Description
|
Product name |
Fully automatic pressure calibrator |
|
Model |
ALKD920C |
|
Pressure range |
-0.95~25bar |
|
Accuracy |
0.02%F.S |
|
Communication |
RS-232 |
|
Output port |
Two |
|
Current Measurement |
-30~30mA |
|
Voltage measurement |
-30~30V |
|
Current output |
0~22mA |
|
DC Output |
24VDC |
|
Temperature range |
5~50℃ |
|
Relative humidity |
≤80%RH |
|
HART function |
Equipped with HART protocol |
|
LCD display |
Press the button to select 5 or 6 digits fordisplay |
|
Overload capacity |
1.2~1.5 times the full range |
|
External dimensions |
370×300×200mm |
|
Weight |
12kg |
|
Product packaging size |
Approximately 18kg |
|
Product packaging weight |
410x340x340mm(packaging material isWooden box) |
|
power supply |
External charger 220VAC 50HZ |
|
Measurement medium |
Clean air |
|
Standard accessories |
Pa、kPa、MPa、psi、bar、mbar、inHg、mmHg、inH2O、mmH2O、kgf/cm² |
|
Annex |
Plug x 2 sealing rings x 2 testing lines x 2 filters x 1 connecting line x 1 Adapter x 1 certificate x 1 instruction manual x 1 |
|
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
|
Output port 1 |
Display |
Navigation assistance key |
Output port 2 |
RS-232 communication interface |
Pressure module |
Power switch key |
Button Description |
Alpha numeric keypad area |
|
1 |
2 |
3 |
4 |
5 |
6 |
|
Switching measurement |
HART connection |
Internal power supply current output |
± 30V voltage measurement |
± 30mA current measurement |
24VDC DC output |
