Description
|
① |
② |
③ |
④ |
⑤ |
⑥ |
|
Pressure Relief Value |
Standard table interface Connecting threads：M20X1.5 |
Oil cup |
Fine-tuning |
Pressure Lever |
Interface of tested instrument Connecting threads：M20X1.5 |
Product Information
|
Product name |
Handheld hydraulic pump |
|
Model |
ALKS506 |
|
Measuring range |
0~700bar(Can be customized) |
|
Environmentalconditions |
Laboratory or field |
|
Environmentaltemperature |
0～50℃ |
|
Way of Pressure |
Hand movement |
|
Connecting threads |
The default thread size for the pressure output port is M20 × 1.5. If other thread sizes are required, such as Bsp 1/2, G1/4, NPT1/4, G1/2, NPT1/2, etc., other special thread sizes can also be customized |
|
Applicable medium |
Transformer oil 25# or pure water |
|
Net weight |
Approximately2.1Kg |
|
Size |
265×265×100mm |
|
Weight of instrumentbox |
Approximately 2.7Kg |
|
Instrument box size |
390×310×250mm |
|
Product weight |
Approximately 6.0kg (packaging material iscardboard box) |
|
Product packaging size |
460×390×270mm |
|
Product standard configuration |
Certificate of conformity x 1 copy Instructions x 1 copy Quality assurance card x 1 copy Sealing ring x 1 pack Instrument box X 1 piece 4 connector sets： G1/4(F) M20x1.5(M)x 1 piece G1/4(M) M20x1.5(M)x 1 piece NPT1/4(F) M20x1.5(M)x 1 piece NPT1/4(M) M20x1.5(M)x 1 piece |
