FM radar level meter alklc080

Description

The level meter alklc080 of FM radar supports the application of four wire system and two wire system. A large range of multiple models of products can reach 120m, and the blind area can reach 8cm. Due to its high frequency and short wavelength, it is suitable for solid applications. The working mode of transmitting and receiving electromagnetic wave through lens has advantages in high dust and harsh temperature (+ 200 ℃). The instrument can be fixed by flange or thread, which makes the installation easy and convenient.

Based on self-researchCMOS millimeter wave radio frequency chip to achieve compact RF architecture, high signal-to-noise ratio,
small blind area. 5GHz operating bandwidth, so that the product has measurement resolution and measurement accuracy.
3 °The antenna beam angle, the interference in the installation environment has little influence on the instrument, and the
installation is convenient.
Wave length, which has reflection characteristics on the solid surface, so there is no need for special use of universal flanges
for aiming. Support remote debugging and remote upgrade, reduce waiting time, improve work efficiency.
Support Bluetooth debugging of mobile phone to facilitate maintenance of field personnel
