Description
01
02
Stainless steel material corrosion-resistant oxidation-resistant
and more durable for use
Multiple ranges available customizable according
to requirements
1
2
3
4
5
6
7
8
Output 1
Connecting standard
tables or checklists
Connecting threads：M20X1.5
Fine tuning
Increase or decrease
pressure within
a small range
Output 2
Connecting
standard tables or
checklists
Connecting threads：
M20X1.5
Pressure
regulating valve
Locks when output
pressure is unstable
to maintain steady
pressure
Pressure
relief valve
Locks during pressure
build-up and opens
during pressure
release
Filling port
Add transformer oil 25#
or purified water
Pressure
application lever
Control the pressure
level by manually
turning the handle
Pump assembly
Assemble and install
various components
Product name
Portable hydraulic pump
Model
ALKB806
Measuring range
0~600bar/0~8700psii/0~60MPa (Pressure selectable)
Adjust the fineness
min 1KPa
Output port
Two
Pressure connection
Quick thread (M20 × 1.5)
Ambient temperature
-10~60℃
Relative humidity
＜85%
Measurement medium
Transformer oil 25# or purified water
Way of Pressure
Usage environment
Net Weight
Approximately 7.1kg
Product size
350×245×130mm
Packaged weight
Approximately 9.0kg(packaging material is cardboard box)
Product packaging size
430×325×210mm
Product standard configuration
Certificate of conformance ×1
User manual ×1
Warranty card ×1
Plugs ×2
