Description
|
01 |
02 |
03 |
|
LCD Display Equipped with temperature compensation More accurate measurement Display environmental temperature measurement Read real-time temperature |
Manufacturing Process Using thin film panels And touch switch attractive design Long lifespan of buttons |
Ergonomic Design Backlight Pressure current display Intuitive, clear, compact and reasonable structure |
|
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
|
Currnt Measurement |
DC24V output |
Display |
Function keys |
Partable handle |
Pressure output (Positive and negative valtage swtvhing) |
Air delivery valve |
Fine adjustment handle |
Pressure handle |
|
Product name |
Portable pressure calibrator |
|
Model |
ALKY25A(Temperature compensation function) |
|
Measuring range |
-0.95~25bar/-13~360psi-0.095~2.5MPa(Optional within the range) |
|
6 pressure units |
bar、kpa、MPa、Psi、mmHg、kgf |
|
Pressure connection |
M20x1.5 |
|
Resolution |
Pressure: Min: 10Pa Current: Min: 1uA |
|
Accuracy |
Pressure:0.05%F.S Current:0.05%±1d |
|
Current measurement |
0~22mA |
|
DC output |
24VCD |
|
Environmental temperature |
0~50℃ |
|
DC working time |
≥16h |
|
Display |
41/2LCD,51/2LCD pressure,current dual display |
|
Relative humidity |
≤80%RH |
|
Overload capacity |
It is 1.2 to 1.5 times the upper limit of the range |
|
Measurement medium |
Clean air |
|
Way of Pressure |
Hand movement |
|
Power supply and power consumption |
220VAC 50Hz 3VA |
|
Charging Voltage |
8.4V |
|
Net weight |
Approximately 2.3Kg |
|
Size |
330×150×120mm |
|
Weight of instrument box |
Approximately 2kg |
|
Instrument box size |
390×290×170mm |
|
Weight after packaging |
Approximately 6 kg (packaging material is cardboard box) |
|
Product packaging size |
420×320×200mm |
|
Product attachments |
Instrument box x 1 Charger x 1 Pressure output pipe (including joint) × 1 Communication pen x 1 Certificate of conformity x 1 Instruction manual × 1 Quality Assurance Card x 1 |
