Description
Alkw150a dry body temperature verification furnace is small in size, fast in heating, stable in temperature control and pollution-free. It can calibrate the temperature sensor and instrument as a whole. It is easy to carry, easy to use, fast and reliable in temperature calibration. It is used in machinery, shipping, chemical industry, food, electric power, medicine and other industries.
Brand: aileike
Model: alkw150a
Type: temperature calibration
Temperature range: - 20 ~ 150 degrees
Instrument accuracy: grade 0.2
Instrument box size: 330 * 165 * 320 mm
Net weight: 7 kg
The stable temperature control instrument is used in the dry body temperature verification furnace, and the alloy material with good thermal conductivity is used for the soaking block. It is in a leading position in the technology of inserted depth, horizontal temperature field and vertical temperature field. In the required temperature range, it can easily set and accurately generate the required temperature.
|
parameter |
Model and specification |
||
|
model |
ALKW150A |
ALKW150B |
ALKW150C |
|
temperature range |
-20℃～150℃ |
35℃~600℃ |
300℃~1200℃ |
|
heat source |
Semiconductor refrigeration / heating |
electrothermal |
electrothermal |
|
Instrument accuracy |
Grade 0.2 |
Grade 0.2 |
Grade 0.2 |
|
Stability |
±0.2℃ |
±0.1℃ |
±0.2℃ |
|
Display resolution |
0.02℃ |
0.02℃ |
0.02℃ |
|
Horizontal temperature field |
≤±0.25℃ |
≤±0.25℃ |
≤±0.25℃ |
|
Well depth |
160mm |
160mm |
160mm |
|
Measuring hole size |
Φ6.8.10.12mm |
Φ6.8.10.12mm |
Φ6.8.10.12mm |
|
Instrument box size |
330×165×320mm |
330×150×320mm |
330×165×320mm |
be careful：Measuring hole size can be processed according to requirements
