Description
|
Product name |
Digital display pressure retention recorder |
||||||
|
Model |
ALKYL101 |
||||||
|
Indication accuracy |
±0.5% |
||||||
|
Recording accuracy |
±0.5% |
||||||
|
Control accuracy |
±0.5% |
||||||
|
Indication insensitive area |
±0.25% |
||||||
|
Travel time |
≤5S |
||||||
|
Setting range |
0~100% |
||||||
|
Effective recording width |
87.5mm |
||||||
|
Power consumption |
≤20VA |
||||||
|
Record the paper feed speed |
24 Hours/Day (default, others customizable) |
||||||
|
Output contact capacity |
AC 220V1A (AC non-inductive load) DC 28V2A (pure resistance load) |
||||||
|
Ambient temperature |
0～50℃ |
||||||
|
Relative humidity |
≤90% |
||||||
|
Power supply |
220V±10% 50Hz±5% |
||||||
|
Power consumption |
≤20VA |
||||||
|
Net weight |
Approximately 8kg |
||||||
|
Product size |
280×280×200mm |
||||||
|
Hole size |
260×260mm |
||||||
|
Packaged weight |
Approximately 10kg |
||||||
|
Product packaging size |
380×380×300mm |
||||||
|
Attached accessories |
Instruction × 1 Certificate × 1 Quality Assurance Card × 1 Fuse × 2 recording pen × 2 recording paper × 30 |
||||||
|
Pressure Range of Pressure Recording Paper |
|||||||
|
0~10 KG |
0~20 KG |
0~30 bar |
|||||
|
0~0.6 MPa |
0~1 MPa |
0~2.5 MPa |
|||||
|
0~4 MPa |
0~6 MPa |
0~20 MPa |
|||||
|
0~25 MPa |
0~40 MPa |
0~60 MPa |
|||||
|
Recorder paper feed speed |
|||||||
|
24 hours per lap (Default) |
12 hours per lap |
4 hours per lap |
2 hours per lap |
1 hour per lap |
|||
