Description
|
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
12 |
13 |
14 |
15 |
16 |
|
Power button |
Power port |
Signal port |
24V power output |
Common terminal |
mA input terminal |
Positive/ Negative pressure switching valve |
Pressure output Installation of the instrument under test connecting threads： M20X1.5
|
Display screen |
With temperature compensation |
Function key |
Pressure output Installation of the instrument under test connecting threads： M20X1.5
|
Pressure relief valve Closes during pressurization opens after measurement completion |
Fine adjustment valve Fine pressure adjustment |
Stop valve Close when approaching the target range then fine-tune |
Hand pump Manual pressure generation |
|
Product name |
Box type pressure calibrator |
|
Model |
ALKY15A (with temperature compensation) |
|
Measuring range |
-0.95~40bar |
|
Relative humidity |
≤80%RH |
|
Ambient temperature |
0~80%RH |
|
DC operating time |
≥16h |
|
Pressure connection |
The default thread size for the pressure output port is M20 × 1.5(F). If you need other thread sizes, please contact us for consultation. |
|
Temperature compensation |
There is (0~50) ℃ |
|
Unit switching |
6 units can be switched |
|
Current measurement |
0~22mA |
|
DC Output |
24VDC |
|
Accuracy |
Pressure: 0.05% F.S Current: 0.05% ± 1d |
|
Display |
41/2LCD, 51/2LCD dual display for pressure, current, and temperature |
|
Load capacity |
1.2 times the upper range limit |
|
Way of Pressure |
Hand movement |
|
Measurement medium |
Clean air |
|
Power supply |
220VAC 50Hz 3VA |
|
Net Weight |
Approximately 6.5kg |
|
Product size |
365×228×320mm |
|
Packaged weight |
Approximately 8kg (packaging material is Wooden box) |
|
Product packaging size |
410×270×360mm |
|
Product standard configuration |
Certificate of conformity x 1 Instruction manual x 1 Charger x 1 Sealing ring x 4 Hoses x 1 Probe x 1 Factory inspection report x 1 |
